Description
LED Premium Strip Light, 45/35/26W, CCT 3500/4000/5000K, 120-347V
CSX1-4PS45-FCCT-H
Order Code:13634
• Unique toolless entry allows for the lens and LED board to be easily removed, allowing quick access to the driver. Simply squeeze the sides together for access
• Controls Ready makes adding controls quick and easy. Includes snap- in a receptacle for Standalone and Networked Lighting Controls
• 2 x 1/2” knockouts on each end
• Linear alignment plate accessory makes row mounting quick and easy
• Junction box cover plate included
• PowerSet feature allows for multiple lumen stops out of the box
• FieldCCeT features provide multiple color temperature settings in one fixture
| Product Specifications | |
|---|---|
| Input Voltage | 120-347VAC |
| Lumens (lm) | 5,850 / 4,550 / 3,380 lm |
| Wattage | 45W / 35W / 26W |
| Efficacy (lm/W) | 130 |
| CCT | 3000K / 4000K / 5000K |
| CRI | 80+ |
| Dimming | 0-10V |
| Nominal Size | 4 Foot |
| Replacement For/Equivalent | 2 lamp 32W T8 |
| Energy Star | No |
| IP Rating | IP20 |
| UL Location Rating | Damp |
| RoHS Compliant | No |
| FCC Compliant | No |
| Dimensions (L x W x H) | L: 47 5/16" (1202 mm), W: 2 13/16" (72 mm), H: 2 1/2" (64 mm) |
| Color | White |
| Lens Material New | Acrylic (PMMA) |
| Operating Temp Range (°F/°C) | -4F to 122F (-20C to 50C) |
| Surge Protection (kV) | 2.5kV |
| Auxiliary Output | 12V, 100mA |
| Brand | EiKO |
