Description
Led AAL Area Light Wattage 80/60/40W, Optic T3/T4/T5, CCT 30/40/50K, 120-347V, 0-10V DIM
Universal Mounting Hardware sold separately:
Part # AAL2-MASF
The EiKO AAL2 LED Area Light sets a new standard for versatility and performance in outdoor lighting. Designed for professionals who demand flexibility on every job, AAL2’s PowerSET, ColorSET, and OpticSET technologies let you fine-tune power, color temperature, and light distribution right in the field-no extra SKUs, no delays. Available in Bronze, White, and Black, every SKU includes an adjustable universal mount in the box, eliminating mounting uncertainty and simplifying installation. From parking lots to campuses and commercial sites, AAL2 reduces inventory, lowers project costs, and delivers exceptional performance right out of the box.
| Product Specifications | |
|---|---|
| Input Voltage | 120-347VAC |
| Lumens (lm) | 11,600 / 8,900 / 6,100 lm |
| Wattage | 80W / 60W / 40W |
| CCT | 3000K / 4000K / 5000K |
| CRI | 80+ |
| Dimming | 0-10V |
| Replacement For/Equivalent | up to 175-320W HID |
| DLC Version | DLC 6.0 Premium |
| Energy Star | No |
| IP Rating | IP65 |
| UL Location Rating | Wet |
| Other Ratings | IK8; VIBRATION RATED: 3G |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| UL / ETL | Yes - UL |
| Dimensions (L x W x H) | 19.17in x 11.10in x 2in |
| Lens Material | Polycarbonate (PC) |
| Operating Temp Range (°F/°C) | -40F to 122F (-40C to 50C) |
| Surge Protection (kV) | 10kV |
| Warranty | 5 Years |
| Brand | EiKO |
