Description
Eaton locking receptacle, #18-10 AWG, 30A, Industrial, 250V, Back wiring, Black, Single, L15-30, Three-pole
Product specifications
| Special features |
Severe duty locking plug
|
| Type |
Locking receptacle
|
| Amperage Rating |
30A
|
| Voltage rating |
3Ø 250 V
|
| Contact material |
Brass
|
| Application |
Industrial
|
| Device grade |
Commercial
|
| Wiring method |
Back
|
| Number of wires |
Grounding
4 |
| Number of poles |
Three-pole
|
| Color |
Black
|
| Material |
Nylon
|
| Operating temperature |
-40 to 70 °C (-40 to 158 °F)
|
| Allowable wire size |
#18-10 AWG
|
| NEMA configuration |
L15-30
|
| Design type |
Single receptacle
|
| Face/body material |
Nylon
|
| Receptacle type |
Single
|
General specifications
| Product Name |
Eaton Arrow Hart locking receptacle
|
| Catalog Number |
L1530R
|
| UPC |
032664533105
|
| Product Length/Depth |
6.5 in
|
| Product Height |
1.5 in
|
| Product Width |
3.5 in
|
| Product Weight |
1.025 lb
|
| Compliances |
Federal Specifications Classification W-C375
RoHS Compliant |
| Certifications |
NOM
UL Listed CSA certified |
