8 Inch 5.5W/8W/11W Commercial Downlight, 120V-277V, CCT Select- TRIAC & 0-10V DIMMING

Part : RCF8T05WCS

Price:
Sale price$33.99

Please contact us for quantity discount

Description

8 Inch 5.5W/8W/11W Commercial Downlight, 120V-277V, CCT Select- TRIAC & 0-10V DIMMING

pdf download

Product Description
The RCF Multi-mode Universal Commercial downlight combines 5 CCTs and 3 Wattages in one product, and features multiple dimming modes (0-10V, TRIAC and ELV), with 12v output making it c-Max controls compatible. Easy to install in new construction, remodel and retrofit projects, with a slim body that fits into shallow ceilings, this Energy Star 1.0-qualified product is an all-in-one solution for adding recessed downlighting to hospitality, retail, office and other commercial lighting applications.

Performance
Watts (W) 5W/8W/11W
Voltage (V) 120-277
Delivered Lumens (lm) 450/750/1000
Efficacy (lm/W) 90
Color Rendering Index (CRI) ≥90
Color Temperature (K) 2700/3000/3500/4000/5000
Equivalent Wattage 16W CFL
Beam Angle 110
Beam Type MEDIUM
Power Factor 0.90
Min. Ambient Temp (°F) -4
Max. Ambient Temp (°F) 104
Lumen Maintenance
L70 (Hours) 50000


Features:
• 2700/3000K/3500K/4000K/5000K CCT Selectable
• Qualified as a fixture and a retrofit
• Mounts directly into ceiling, no housing required
• Extra wide flange to cover oversize openings
• Input Voltage: 120-277V
• Dimming: TRIAC/ELV with 12V & 0-10V
• Beam angle: 100°
• CRI: >90
