2 Foot Selectable LED Linear Wraparound Fixture
2 Foot Selectable LED Linear Wraparound Fixture
2 Foot Selectable LED Linear Wraparound Fixture
2 Foot Selectable LED Linear Wraparound Fixture

2 Foot Selectable LED Linear Wraparound Fixture

Nicor
Part : WPC3224WSUS8WH
Price:
$40.55

Please contact us for quantity discount

Description

2 Foot Selectable LED Linear Wraparound Fixture

The WPC3 LED Linear Wrap is an economical, energy-efficient lighting alternative to traditional fluorescent wrap fixtures. The WPC3's modern design features a curved, milky white lens that offers a more polished aesthetic while eliminating hotspots. Available with CCT and lumen output Selectable options with the choice of 3500K, 4000K, or 5000K CCTs and low, medium, and high lumen output. This versatile fixture is easy to surface mount on ceilings and walls, making it ideal for general ambient lighting in retail, warehouse, residential utility, and light commercial or industrial applications.


Features
  • 2-Foot Length
  • 3 Selectable Color Temperatures (3500K, 4000K, 5000K)
  • 3 Selectable Wattages (16W, 20W, 24W)
  • Produces up to 2936 Lumens (varies by settings)
  • Features a durable steel-constructed frame
  • Includes a precision engineered polystyrene diffuser lens
  • Damp-Location Rated and DLC Listed
  • Dual Voltage: 120-277VAC
  • Built-in LEDs, built-in driver
  • Ready to install right out of the box. No other parts required
  • Protected by NICOR's 5-Year Limited Warranty



SPECS



Size (Ft.)
2
Product Color
White
Finish
Powder Coat
Light Source
LED
Wattage
16 (Standard)
20.4 (Medium)
24.1 (High)
Wattage Equivalent
150
Lumen Output
1995 (3500K at 16W)
2100 (4000K at 16W)
2007 (5000K at 16W)
2464 (3500K at 20.4W)
2593 (4000K at 20.4W)
2478 (5000K at 20.4W)
2790 (3500K at 24.1W)
2936 (4000K at 24.1W)
2806 (5000K at 24.1W)
Lumens Per Watt
125 (3500K at 16W)
131.6 (4000K at 16W)
125.7 (5000K at 16W)
120.7 (3500K at 20.4W)
127 (4000K at 20.4W)
121.4 (5000K at 20.4W)
115.8 (3500K at 24.1W)
121.9 (4000K at 24.1W)
116.5 (5000K at 24.1W)
Color Temperature (CCT)
3500K
4000K
5000K
CRI
82
Dimmable?
Yes
Dimming Type
0-10VDC
Operating Temperature
-4˚F to 122˚F (-20˚C to 50˚C)
Listings/Certifications
UL Certified
Damp-Location
cUL 1598 Listed
UL 1598 Listed
RoHS Compliant
FCC Class A
